Start-up
23
6. Lift the "Milk Shuttle" by the drawbar ➊ so that the transport block under the
feed container
➋ can be removed.
7. Adjust the drawbar handle as described in chapter 5.4.
8. Slowly push the Milk Shuttle off the pallet. While doing so, make sure that both
rear wheels set down at the same time.
5.4 Adjust the drawbar handle
Required tools: Hexagon spanner 6 mm
Carry out the following steps to adjust the drawbar handle:
1. Loosen hexagon socket screw (1) with Allen key.
2. Adjust the drawbar handle to the required height.
3. Tighten the hexagon socket screw (1) again.
CAUTION
Before moving the Milk Shuttle, familiarize yourself with the operation of the con-
trollers (chapter 6.5).
CAUTION
Figure 5/2: Adjusting the drawbar handle
CAUTION
When adjusting the drawbar head, make sure no cables are pinched or over-
stretched.
CAUTION
