Urban MilkShuttle User Manual

What if...
60
Troubleshooting
• Connect or replace temperature sensor of
heating element 1 (connected to left heating control circuit board with address 1 assigned)
• Connect or replace temperature sensor of
heating element 2 (connected to right heating control circuit board with address 2 assigned)
• Connect or replace temperature sensors of
both heating elements 1 and 2
• Connect or replace temperature sensor of
medium in container (connected to central control circuit board DIMA220)
• Connect or replace both the temperature
sensor of the medium and the temperature sensor of heating element 1
• Connect or replace both the temperature
sensor of the medium and the temperature sensor of heating element 2
• Connect or replace both the temperature
sensor of the medium and the temperature sensors of both heating elements (1+2)
Fault description Depending on the fault code, either one or several temperature sensors are not connected or have an open cable break. The numerical code 199 in the second line of
the message indicates which temperature sensor is defective.
199.0 199.0 199.0
DIMA AC1 AC2
AC1
 circuit board for heating control with
address 1 assigned (left board, type AC230L31)
AC2
 circuit board for heating control with
address 2 assigned (right board, type AC230L31)
DIMA
 circuit board for central control (module
DIMA220)
Display message
21 Fault Temperature 22.9 199.0 52.3 g 22 Fault Temperature 22.9 48.4 199.0 23 Fault Temperature 22.9 199.0 199.0 24 Fault Temperature 199.0 48.4 52.3 25 Fault Temperature 199.0 199.0 52.3 26 Fault Temperature 199.0 48.4 199.0 27 Fault Temperature 199.0 199.0 199.0
No. Type 21 1 22 1 23 1 24 1 25 1 26 1 27 1
