USTER® HVI 1000 Instruction Manual
Uster Technologies, Inc. Chapter 2
(10/07) Installation - Page 2-8
• Host Com
Connect the Host COM to the connector labeled COM4, Lava
Quattro Port A, on the rear of the
computer.
• LS Controller
Connect the LS Control Board to the connector labeled COM1 on
the rear of the computer.
• MIC Controller
Connect the MIC Control Board to the connector labeled COM2
on the rear of the computer.
• Moisture Controller
Connect the Moisture Control Board to the connector labeled
COM6 on the rear of the
computer.
The HVI 1000 system is now ready to power ON.
