USTER® HVI 1000 Instruction Manual
Uster Technologies, Inc. Chapter 5
(3/08) Calibration - Page 5-22
To edit/change the Color Tile Calibration tolerance values:
1. Click the Setup Tolerances button to launch the window.
2. Click the text box to place the cursor inside the box.
3. Use the keyboard to type in the appropriate values for Rd and
+b.
4. Click OK.
5. Click Cancel to exit without changing the values.
5.1.2 Setup References
You must enter a valid password before entering this area. To
edit/change the Color Tile Calibration reference values:
1. Click the Setup
References button to
launch the window.
2. Click the text box to
place the cursor inside
the box.
3. Use the keyboard to
type in the appropriate
values for Rd and +b.
4. Click OK.
5. Click Cancel to exit
without changing the
values.
Figure 5-14: Setup Color Tile References
