technical data vacon • 97
24-hour support +358 (0)40 837 1150 • Email: vacon@vacon.com
10
10.2.2 Vacon 10 – Mains voltage 115 V
10.2.3 Vacon 10 – Mains voltage 380-480 V
* The maximum ambient operating temperature of these drives is +50 °C.
Mains voltage 115 V, 50/60 Hz, 1~ series
Freq.
converter
type
Rated loadability
Motor shaft
power
Nominal
input
current
Mechanical
size
Weight
(Kg)
100% contin.
current I
N
[ A ]
150% over-
load current
[ A ]
P
[ HP ]
P
[ KW ]
[ A ]
0001 1.7 2.6 0.33 0.25 9.2 MI2 0.7
0002 2.4 3.6 0.5 0.37 11.6 MI2 0.7
0003 2.8 4.2 0.75 0.55 12.4 MI2 0.7
0004 3.7 5.6 1 0.75 15 MI2 0.7
0005 4.8 7.2 1.5 1.1 16.5 MI3 0.99
Table 10.4: Vacon 10 power ratings, 115 V, 1~
Mains voltage 380-480 V, 50/60 Hz, 3~ series
Freq.
converter
type
Rated loadability
Motor shaft
power
Nominal
input
current
Mechanical
size
Weight
(kg)
100% contin.
current I
N
[ A
]
150% over-
load current
[ A ]
P
[ HP ]
P
[ KW ]
[ A ]
0001 1.3 2 0.5 0.37 2.2 MI1 0.55
0002 1.9 2.9 0.75 0.55 2.8 MI1 0.55
0003 2.4 3.6 1 0.75 3.2 MI1 0.55
0004 3.3 5 1.5 1.1 4 MI2 0.7
0005 4.3 6.5 2 1.5 5.6 MI2 0.7
0006 5.6 8.4 3 2.2 7.3 MI2 0.7
0008 7.6 11.4 4 3 9.6 MI3 0,99
0009 9 13.5 5 4 11.5 MI3 0.99
0012 12 18 7.5 5.5 14.,9 MI3 0.99
Table 10.5: Vacon 10 power ratings, 380-480 V
