96 vacon technical data
Tel. +358 (0)201 2121 • Fax +358 (0)201 212205
10
10.2 Power ratings
10.2.1 Vacon 10 – Mains voltage 208-240 V
* The maximum ambient operating temperature of these drives is +40 °C.
Mains voltage 208-240 V, 50/60 Hz, 1~ series
Freq.
converter
type
Rated loadability
Motor shaft
power
Nominal
input
current
Mechanical
size
Weight
(kg)
100% contin.
current I
N
[ A ]
150% over-
load current
[ A ]
P
[HP ]
P
[KW]
[ A ]
0001 1.7 2.6 0.33 0.25 4.2 MI1 0.55
0002 2.4 3.6 0.5 0.37 5.7 MI1 0.55
0003 2.8 4.2 0.75 0.55 6.6 MI1 0.55
0004 3.7 5.6 1 0.75 8.3 MI2 0.55
0005 4.8 7.2 1.5 1.1 11.2 MI2 0.7
0007 7 10.5 2 1.5 14.1 MI2 0.7
0009* 9.6 14.4 3 2.2 22.1 MI3 0.99
Table 10.2:Vacon 10 power ratings, 208-240 V
* The maximum ambient operating temperature of this drive is 40 °C!
Mains voltage 208 - 240 V, 50/60 Hz, 3~ series
Freq.
converter
type
Rated loadability
Motor shaft
power
Nominal
input
current
Mechanical
size
Weight
(kg)
100% contin.
current I
N
[ A ]
150% over-
load current
[ A ]
P
HP
P
[ KW ]
[ A ]
0001 1.7 2.6 0.33 0.25 2.7 MI1 0.55
0002 2.4 3.6 0.5 0.37 3.5 MI1 0.55
0003 2.8 4.2 0.75 0.55 3.8 MI1 0.55
0004 3.7 5.6 1 0.75 4.3 MI2 0.7
0005 4.8 7.2 1.5 1.1 6.8 MI2 0.7
0007* 7 10.5 2 1.5 8.4 MI2 0.7
0011* 11 16.5 3 2.2 13.4 MI3 0.99
Table 10.3: Vacon 10 power ratings, 208-240 V, 3~
