Vacon 10 - Frequency References (Control Panel: Menu PAR -> P3)

54 • vacon parameters
Tel. +358 (0)201 2121 • Fax +358 (0)201 212205
8
8.4 Frequency references (Control panel: Menu PAR -> P3)
NOTE! These parameters are shown, when P17.2 = 0.
Code Parameter Min Max Unit Default ID Note
Min frequency 0,00 P3.2 Hz 0,00 101
Max frequency P3.1 320,00 Hz
50,00 /
60,00
102
P3.3
Remote Control
Place 1 fre-
quency refer-
ence selection
16 4117
1 = Preset Speeds 0
2 = Keypad
3 = Fieldbus
4 = AI1
5 = AI2
6 = PI
P3.4 Preset speed 0 P3.1 P3.2 Hz 5,00 124 Activated by digital inputs
P3.5 Preset speed 1 P3.1 P3.2 Hz 10,00 105 Activated by digital inputs
P3.6 Preset speed 2 P3.1 P3.2 Hz 15,00 106 Activated by digital inputs
P3.7 Preset speed 3 P3.1 P3.2 Hz 20,00 126 Activated by digital inputs
P3.8 Preset speed 4 P3.1 P3.2 Hz 25,00 127 Activated by digital inputs
P3.9 Preset speed 5 P3.1 P3.2 Hz 30,00 128 Activated by digital inputs
P3.10 Preset speed 6 P3.1 P3.2 Hz 40,00 129 Activated by digital inputs
P3.11 Preset speed 7 P3.1 P3.2 Hz 50,00 130 Activated by digital inputs
Table 8.4: Frequency references
