technical data vacon • 95
24-hour support +358 (0)40 837 1150 • Email: vacon@vacon.com
10
Ambient
conditions
Ambient operating
temperature
-10 °C (no frost)…+40 / 50°C (depends on the unit size):
r
a
ted loadability I
N
Side by side installation for MI1-3 it is always 40°C; For
IP21/Nema1 option in MI1-3 the maximum temparture
is also 40 °C.
Storage temperature -40°C…+70°C
Relative humidity
0…95% RH, non-condensing, non-corrosive, no dripping
wat
er
Air quality:
- chemical vapours
- mech. particles
IEC 721-3-3, unit in operation, class 3C2
IEC 721-3-3, unit in operation, class 3S2
Altitude
100% load capacity (no derating) up to 1000 m. 1% der-
ating for each 100 m above 1000 m; max. 2000 m
Vibration:
EN60068-2-6
3...150 Hz
Displacement amplitude 1(peak) mm at 3...15.8 Hz Max
acc
e
leration amplitude 1 G at 15.8...150 Hz
Shock
IEC 68-2-27
UPS Drop Test (for applicable UPS weights)
Storage and shipping: max 15 G, 11 ms (in package)
Enclosure class IP20 / IP21 / Nema1 for MI1-3.
Pollution degree
PD2
EMC
Immunity Complies with EN50082-1, -2, EN61800-3
Emissions
230V : Complies with EMC category C2; With an internal
RFI fi
lter.
400V: Complies with EMC category C2; With an internal
RFI fi
lter
Both: No EMC emission protection (Vacon level N):
Without RFI filter
Standards
For EMC: EN61800-3,
For safety: UL508C, EN61800-5
Certificates
and manufac-
turer’s decla-
rations of
con
formity
For safety: CB, CE, UL, cUL,
For EMC: CE, CB, c-tick
(see unit nameplate for more detailed approvals)
Table 10.1: Vacon 10 technical data
