22 • vacon installation
Tel. +358 (0)201 2121 • Fax +358 (0)201 212205
3
Figure 3.9: Open the lid, MI1 - MI3
Figure 3.10: Install the control cables. MI1 - MI3. See Chapter 6.2
Strip the plastic
cable coating for
360
°
earthing
Control cable
tightening
torque: 0.4 Nm
