58
7.2.1.5.4 Idle mode (menu 1.5.3)
After the flush sequence has finished and idle mode has been reached the system is ready for
discharge operations.
The system stays idle until the operator enters the next command.
From idle mode the following modes can be selected:
? information mode (menu 1.5.3.1)
STOP shutdown mode (menu 1.5.3.2)
CHANGE extended setup mode (menu 1.5.3.3)
SELFTEST self test menu (menu 1.5.3.4)
SAMPLE sample menu (menu 1.5.3.5)
7.2.1.5.4.1 Information mode (menu 1.5.3.1)
The information mode is entered when the < ? > key is pressed in menu 1.5.3.
The mode gives additional information about system operation and operational actions which can be
taken if e.g. an alarm situation occurs.
Depending from which menu the information mode is activated, different texts will be displayed.
Figure 49
In menu 1.5.3.1 a text with a short description about the use of the MCU in idle mode is given:
In the “Idle” mode the system is ready for sampling and is waiting for a command.
Other commands in “Idle” mode are:
Selection of (extra) SETUP by CHANGE
Selection of SELFTEST
Start Sampling by SAMPLE
.
CONTROL Sample point: 1 22-11-11
standby Oil type: 5 10:38
version: 0.51S13 & 1.54
In the 'Idle' mode the system is ready for
sampling and is waiting for a command.
Other commands in 'Idle' mode are:
Selection of (ext ra) SETUP by CHANGE
Selection of SELFTEST
Start Sampling by SAMPLE.
