7.2.1.5.4.5.5 Self test mode (menu 1.5.3.5.5)
The selftest mode is entered when the <SELFTEST> key is pressed in menu 1.5.3.5.5.
In the self test mode and internal loop is checked and an overview is displayed of all alarms since
the MCU is last powered down.
Figure 58
There is also a <BUZZER> key to test the internal buzzer. When the key is pressed the buzzer will
sound for approximately 2.5 seconds.
7.2.1.5.4.5.6 Sample setup mode (menu 1.5.3.5.6)
The sample setup mode is entered when the <CHANGE> key is pressed in menu 1.5.3.5.
In menus 1.5.2.1 – 1.5.2.13 and menus 1.5.3.3.1 - 1.5.3.3.9 the system has been setup for a
specific discharge operation. With these menus it is not possible to change parameters during
operations.
With this sample setup menu it is possible to change a limited set of parameters while a discharge
operation is being conducted.
Figure 59
The following settings in the sample setup menu (menu 1.5.3.5.6.1 - 1.5.3.5.6.4) can be set:
Menu Description Range Remark
1.5.3.5.6.1
Speed indication automatic / 0…40 knots Speed indication can be Automatic(A) or Manual(M).
Automatic can be selected by pushing the - button.
Manual can be selected by pushing the + button.
1.5.3.5.6.2
Flowrate indication automatic / 0…32,000 m³/h Flow rate can be Automatic(A) or Manual(M).
Automatic selection must be made in IDLE SETUP/SETUP
menu. Manual selection by entering a value in the SAMPLE
SETUP menu
1.5.3.5.6.3
Oil concentration indication automatic / 0…1,000 ppm Oil concentration can be Automatic(A) or Manual(M).
Automatic selection must be made in IDLE SETUP/SETUP
menu. Manual selection by entering a value in the SAMPLE
SETUP menu.
1.5.3.5.6.4
Display contrast 710…790 Display contrast can be set between 710 and 790.
Default is 750.
When all parameters are set and the <BACK> key is pressed the system will return to sample mode
(menu 1.5.3.5)
CONTROL Sample point: 1 22-11-11
selftest Oil type: 5 10:38
2011-11-21 14:57 - Bad shutdown
EPU: OK
free: 1927296 kB
BUZZERBACK
CONTROL Sample point: 1 22-11-11
sample setup Oil type: 5 10:38
speed ind. automatic
flowrate ind. automatic
oil conc. ind. automatic
display contrast 750
? CHANGEBACK
