49
7.2.1.2 Configuration mode (menu 1.2)
The configuration mode is entered when the <CONFIG> key is pressed in the menu 1.
The mode is used to set up the system during installation and this should only be done by a trained
service engineer.
Prior to entering the settings, the operator must familiarise themselves with the system and also the
following information. The majority of this information can be located on the vessel’s IOPP
certificate:
Max range of flowmeter (if fitted)
Pulses per nautical mile, ship’s speed log input (if fitted), ship’s GPS
Ship’s deadweight
Status of the ship
How many sampling points are fitted on the vessel and the denomination of each
In order to configure the system to the ship’s specific requirements it is necessary to enter specific
parameter setting.
Figure 38
To enter the parameter setting
The system has to be in the standby mode
Press the <CONFIG> key to enter the setup mode (Menu 1.2)
Enter password: 729
In the configuration mode the settings can be changed by either entering a numeric value or by
selecting a preset value. Different preset values can be selected by pressing < + > or < - >.
Selecting a different setting is done by pressing the <PRV> or <NXT> key and thereby scrolling
through the different settings.
For example, by entering a numeric value with the < 0...9 > keys the setting for the maximum flow of
Flowmeter 1 at 20 mA (menu 1.2.1) can be entered.
Figure 39
By pressing the <CLR> key the value is cleared after which the setting can be entered.
CONTROL 22-11-11
config Oil type: 5 10:38
Enter code: X X X
BACK
32
1
0
65
4
CLR
9
8
7
OK
CONTROL 22-11-11
config Oil type: 5 10:38
Max. flow Flowmeter 1 at 20 mA
range 0 ..32000 m3/h
550 m3/h
OK
32
1
0
65
4
CLR
9
8
7
NXT
PRV
