Chapter 3 ________________________________________________________________ Installation
VAISALA ________________________________________________________________________ 21
CHAPTER 3
INSTALLATION
This chapter provides you with information that is intended to help you
install the HMP60 and HMP110 series probes.
NOTE
n HMP60 or HMP110 series probe to a device, it is
recommended to power off the device.
Dimensions for HMP60, HMP110, and HMP110T
0912-103
Figure 14 HMP60, HMP110, and HMP110T Dimensions
0912-102
Figure 15 Installation with Plastic M12 Nuts, Dimensions
