More information
‣
Clear adjustment of RH measurement (page 47)
7.3.3 1-point adjustment of T measurement (HMP110, HMP113,
and HMP110T)
You can also use Vaisala Insight software for performing calibration and
adjustment. See Vaisala Insight software (page 31).
To perform a 1-point adjustment to the temperature measurement of the HMP110, HMP113, or
HMP110T using serial line, you need:
• Vaisala USB cable (item code 219690)
• PC with a terminal application
• One known and stable temperature reference
1. Connect the USB cable to the PC, but do not connect it to the probe yet.
2. Remove the filter from the probe and insert the probe in the temperature reference.
3. Start a terminal application and set the correct connection settings. The default serial
settings are 19200 8 N 1. Remember to check which COM port the USB cable is using.
4. Wait for 20 … 40 minutes for the temperature to stabilize.
5. Start the terminal session and connect the USB cable to the probe. If your probe is in the
analog output mode, you need to press ENTER a few times to start it in RS-485 mode.
6. Verify that the connection works by giving the ? command.
?
If the probe does not respond with device information:
• Disconnect the USB cable from the probe and retry. If your probe is in the analog
output mode, press ENTER a few times immediately after connecting the USB cable.
• Try the ?? command in case the probe is in POLL mode, open the line using OPEN
command if necessary.
• Check your serial line settings and cable connections.
7. When your serial connection is working, use the L command to see the current user
adjustment parameters.
l
8. Use the ERRS command to see that no errors are active.
errs
HMP60 and HMP110 Series User Guide M211060EN-J
60
