USER'S GUIDE____________________________________________________________________
12 __________________________________________________________________ M010117EN-H
Standard RT20A Sounding Procedure
The numbered list below states the steps and tasks included in a standard
sounding procedure with RT20A. Detailed operating instructions are
given in the same order in the sections below.
NOTE
Note that the numbered list introduces the standard sounding procedure
tasks usually performed with RT20A. The tasks vary according to the
sounding system configuration.
1. Power up the system.
2. Align the RT20A.
3. Start the sounding.
4. Prepare the balloon.
5. Enter the calibration coefficients.
6. Select radiosonde type and properties.
7. Select triggering profile.
8. Enter station data and front direction angle.
9. Tune the receiver.
10. Set the RT20A in AUTO Tracking mode.
11. Release the balloon.
12. Perform the necessary tasks during the flight.
13. End the sounding.
Step 1: Powering Up the System
1. If the DigiCORA PC is running, switch it off.
Before you switch the DigiCORA PC on, make sure that an active
device (Ethernet switch or SPSxxx) is connected to RJ-45 (LAN)
connector. If the active device is SPSxxx, it must be running.
If no active device is connected to the DigiCORA PC, switch
DigiCORA off, connect the active device to RJ-45 (LAN)
connector, and switch DigiCORA PC on. If you use SPSxxx as the
active device, it must be switched on 3 minutes before switching
power on to DigiCORA PC.
2. Make sure that the Hand Terminal RTH21 is connected to the
RTE21 elevation unit.
