VAMP 210 User Manual

VAMP 210 Generator protection relay
Operation and configuration
VAMP Ltd
16
Vamp 24h support phone: +358 (0)20 753 3264 VM210.EN004
Bus (Protocols)
• PROTOCOL
• MODBUS
• SPABUS SLAVE
• IEC-103
• Profibus DP
• TCP/IP
3.1.2. Basic menu structure of protection functions
Example I>:
I>STATUS:
Status Trip State of protection function (-, Start, Trip, Blocked)
SCntr 8 Start counter
TCntr 7 Trip counter
Force Off Forced operation of state (ON, OFF)
SET I> (several SET menus possible):
ILmax 100A Actual value, the value on which the protection is based
Status - State of protection function (-, Start, Trip, Blocked)
I> 110A Set value of protection function [A]
I> 1.10pu Set value of protection function [pu]
curve DT Selection of delay characteristic (DT, NI, VI, EI, LTI)
t> 0.30s
LOG I>:
Index 1 Order number of start 1 – 8, 1=latest
Type - Recorded event data
Flt A Fault current
Load A Current before fault
EDly % Elapsed delay, 100% = tripped
LOG2 I>:
Index 1 Order number of start 1 – 8, 1=latest
2002-08-22 Time stamp of event
20:34:11
67ms
I> event mask:
St_On Start on event
St_Off Start off event
Tr_On Trip on event
Tr_Off Trip off event
