VAMP Ltd Generator protection relay
Operation and configuration
VAMP 210
VM210.EN004 Vamp 24h support phone: +358 (0)20 753 3264
19
4. Operating measures
General
Carefully study the operating instructions in chapters 1
through 3 of this manual before taking any operating measures
or changing any relay settings or functions.
The relay can be controlled from the relay front panel, from a
PC running the VAMPSET software, from a PC running a
suitable terminal software, or from a remote control system.
4.1. Measured data
The measured values can be read from the main menu MEAS
and its submenus.
Submenu CURRENTS
The CURRENTS display shows a list of parameters and their
values.
curren
MEAS
Evnt
DI
DO
Prot
CURRENTS
IL1
IL2
IL3
Io
f
308A
317A
309A
0.16A
50.010Hz
Figure 4.1-1 Current and frequency data.
