VAMP 210 User Manual

VAMP 210 Generator protection relay
Technical description
VAMP Ltd
50
Vamp 24h support phone: +358 (0)20 753 3264 VM210.EN004
5.2.5. Casing
Degree of protection (IEC 60529) IP20
Dimensions (W x H x D) 208 x 155 x 225 mm
Material 1 mm steel plate
Weight 4.2 kg
Color code RAL 7032 (Casing) / RAL 7035 (Back plate)
5.2.6. Package
Dimensions (W x H x D) 215 * 160 * 275
Weight (Relay, Package and Manual) 5.2 kg
5.3. Protection stages
5.3.1. Overcurrent protection stages
Overcurrent stage I> (50/51)
Setting range 0.10 – 4.00 x I
gn
Definite time function:
- Operating time 0.08 – 300.00 s (step 0.02 s)**
IDMT function:
- 4 curve groups (IEC 60255-3) EI, VI, NI, LTI *)
- Time multiplier T
p
0.05 – 3.20
Start time <60 ms
Reset time <60 ms
Reset ratio 0.97
Inaccuracy:
- Starting ±2% of set value
- Operate time at definite time function ±1% or ±30 ms
- Operate time at IDMT function ±5% or at least ±30 ms (I< 50 x I
n
and I< Iset
*20)
*) EI = Extremely Inverse, NI = Normal Inverse, VI = Very Inverse, LTI = Long Time Inverse
**) This is the instantaneous time i.e. the minimum total operational time including the fault
detection time and operation time of the trip contacts.
Overcurrent stage I>> (50/51)
Setting range 0.10 – 20.00 x I
gn
Definite time function:
- Operating time 0.04 – 300.00 s (step 0.01 s)*
Start time <30 ms
Reset time <60 ms
Reset ratio 0.97
Inaccuracy:
- Starting ±2% of set value
- Operate time ±1% or ±25 ms
*) This is the instantaneous time i.e. the minimum total operational time including the fault
detection time and operation time of the trip contacts.
