5.2. Tests and environmental conditions
5.2.1. Disturbance tests (EN 50263)
Emission
- Conducted (EN 55022) 0.15 - 30 MHz
- Emitted (EN 55022) 30 - 1 000 MHz
Immunity
- Static discharge (ESD) EN 61000-4-2, class III
6 kV contact discharge
8 kV air discharge
- Fast transients (EFT) EN 61000-4-4, class III
2 kV, 5/50 ns, 5 kHz, +/-
- Surge EN 61000-4-5, class III
1 kV, 1.2/50 µs, common mode
2 kV, 1.2/50 µs, differential mode
- Conducted RF field EN 61000-4-6
0.15 - 80 MHz, 10 V/m, 80% AM (1 kHz)
- Emitted RF field EN 61000-4-3
80 - 1000 MHz, 10 V/m, 80% AM (1 kHz)
- GSM test EN 61000-4-3
900 MHz, 10 V/m, pulse modulated
1 MHz burst IEC 60255-22-1
1 kV, differential mode
2,5 kV, common mode
Voltage interruption IEC 60255-11
5.2.2. Test voltages
Insulation test voltage
(IEC 60255-5)
2 kV, 50 Hz, 1 min
Surge voltage (IEC 60255-5)
5 kV, 1.2/50 µs, 0.5 J
5.2.3. Mechanical tests
Vibration (IEC 60255-21-1) 10...60 Hz, amplitude ±0.035 mm
60...150 Hz, acceleration 0.5g
sweep rate 1 octave/min
20 periods in X-, Y- and Z axis direction
Shock (IEC 60255-21-1) half sine, acceleration 5 g, duration 11 ms
3 shocks in X-, Y- and Z axis direction
5.2.4. Environmental conditions
Operating temperature 0 to +55°C
Transport and storage temperature -40 to +70°C
Relative humidity < 75% (1 year, average value)
< 90% (30 days per year, no condensation
permitted)
