Operation and configuration
2 Local panel user interface
2.3 Operating measures
VM259.EN007
VAMP 24h support phone +358 (0)20 753 3264
25
Value
Menu/Submenu
Description
E+.nn
E/DECIMAL COUNT
Decimals of exported energy [ ]
Eq.nn
E/DECIMAL COUNT
Decimals of reactive energy [ ]
E-.nn
E/DECIMAL COUNT
Decimals of imported energy [ ]
Ewrap
E/DECIMAL COUNT
Energy control
E+
E/E-PULSE SIZES
Pulse size of exported energy [kWh]
Eq+
E/E-PULSE SIZES
Pulse size of exported reactive energy
[kvar]
E-
E/E-PULSE SIZES
Pulse size of imported energy [kWh]
Eq-
E/E-PULSE SIZES
Pulse duration of imported reactive
energy [ms]
E+
E/E-PULSE DURATION
Pulse duration of exported energy
[ms]
Eq+
E/E-PULSE DURATION
Pulse duration of exported reactive
energy [ms]
E-
E/E-PULSE DURATION
Pulse duration of imported energy
[ms]
Eq-
E/E-PULSE DURATION
Pulse duration of imported reactive
energy [ms]
E+
E/E-pulse TEST
Test the exported energy pulse [ ]
Eq+
E/E-pulse TEST
Test the exported reactive energy [ ]
E-
E/E-pulse TEST
Test the imported energy [ ]
Eq-
E/E-pulse TEST
Test the imported reactive energy [ ]
IL1
I/PHASE CURRENTS
Phase current IL1 [A]
IL2
I/PHASE CURRENTS
Phase current IL2 [A]
IL3
I/PHASE CURRENTS
Phase current IL3 [A]
IL1da
I/PHASE CURRENTS
15 min average for IL1 [A]
IL2da
I/PHASE CURRENTS
15 min average for IL2 [A]
IL3da
I/PHASE CURRENTS
15 min average for IL3 [A]
Io
I/SYMMETRIC
CURRENTS
Primary value of zerosequence/
residual current Io [A]
IoC
I/SYMMETRIC
CURRENTS
Calculated Io [A]
I1
I/SYMMETRIC
CURRENTS
Positive sequence current [A]
I2
I/SYMMETRIC
CURRENTS
Negative sequence current [A]
I2/I1
I/SYMMETRIC
CURRENTS
Negative sequence current related to
positive sequence current (for
unbalance protection) [%]
THDIL
I/HARM. DISTORTION
Total harmonic distortion of the mean
value of phase currents [%]
THDIL1
I/HARM. DISTORTION
Total harmonic distortion of phase
current IL1 [%]
THDIL2
I/HARM. DISTORTION
Total harmonic distortion of phase
current IL2 [%]
THDIL3
I/HARM. DISTORTION
Total harmonic distortion of phase
current IL3 [%]
