Terminal X8 (VAMP 259-3C8)
No:
Symbol
Description
1
T14
Trip relay 14/
2
T14
Trip relay 14/
3
T13
Trip relay 13/
4
T13
Trip relay 13/
5
T21
Trip relay 12/
6
T12
Trip relay 12/
7
T11
Trip relay 11/
8
T11
Trip relay 11/
9
T10
Trip relay 10/
10
T10
Trip relay 10/
11
T9
Trip relay 9/
12
T9
Trip relay 9/
13
T8
Trip relay 8/ Digital input 32
14
T8
Trip relay 8/ Digital input 32
15
T7
Trip relay 7/ Digital input 31
16
T7
Trip relay 7/ Digital input 31
17
T6
Trip relay 6/ Digital input 30
18
T6
Trip relay 6/ Digital input 30
19
T5
Trip relay 5/ Digital input 29
20
T5
Trip relay 5/ Digital input 29
Terminal X6
No:
Symbol
Description
1
BI
External arc light input
2
BO
Arc light output
3
COM
Common connector of arc light I/O
4
S1>+
Arc sensor 1, positive connector *
5
S1>
Arc sensor 1, negative connector *
6
S2>+
Arc sensor 2, positive connector *
7
S2>
Arc sensor 2, negative connector *
*) Arc sensor itself is polarity free
Terminal X6 with DI19/DI20 option
No:
Symbol
Description
1
DI19
Digital input 19
2
DI19
Digital input 19
3
DI20
Digital input 20
4
DI20
Digital input 20
5
--
--
6
S1>+
Arc sensor 1, positive connector *
7
S1>
Arc sensor 1, negative connector *
*) Arc sensor itself is polarity free
