3 Design and Function
3.1 Design
1 Plate seal 6 Integrated controller
2 Body seal 7 Rotary feed through seals
3 Shaft feed through seals 8 Pendulum plate
4 Bonnet seal 9 Sealing ring
5 Actuator
1 2 3 4
5
9 8 7
6
