To clean the nozzles, proceed as follows:
- bring the telescopic nozzle in lower position lowering
the handle.
- remove the cover and disconnect the beverage hoses
- rotate the flow divider coffee nozzle 45° towards your-
self, in order to lift it off the nozzle support
- remove the flow divider, the milker nozzle (if present)
and the instant beverages nozzles.
- For models with cappuccino maker, separate all the
parts of the milker nozzle and check the state of wear
of the seals, replacing them, if necessary
- proceed with the sanitization of all the components
taking care to remove residues and films visible using
swabs or brushes, if necessary.
1
2
3
4
Fig. 31
Models with cappuccino maker
1- Telescopic nozzle handle
2- Milker nozzle
3- Mobile nozzles cover
4- Flow divider nozzle
1
2
3
Fig. 32
Models without cappuccino maker
1- Telescopic nozzle handle
2- Mobile nozzles cover
3- Coffee nozzle
