ENGINE DISASSEMBLY AND ASSEMBLY
DISASSEMBLY ASSEMBLY
Guide-fan cover/ fan cover/carburetor Left crankcase assy./gearbox assy.
Left crankcase cover/gasket gearbox
Outside part of left crankcase Crankshaft/left and right crank case/Starter
motor
Chain adjustor /cylinder head cover Oil pump/starter-clutch/electric start
transmission gear
Camshaft holder/cam Right crankcase cover/oil filter/oil gauge
Cylinder cover/gasket/pin Stator coil/flywheel/cooling fan
Cylinder/gasket/pin Piston/piston pin/circlip
Spring clip/piston pin/piston cylinder/gasket/ dowel pin
Cooling Fan /flywheel/ Stator coil cylinder cover/gasket/ dowel pin
Right crankcase cover/oil filter/oil gauge Cam/camshaft holder
Right crankcase outside Chain adjustor/cylinder head cover
Start motor/left and right crankcase/crank Left crankcase outside assy.
Gearbox Left crankcase cover/gasket/ dowel pin
Left crankcase/gearbox cover Guide fan cover/fan cover/carburetor
NOTE:
• Before installation, wash engine parts, and lubricate, refer to recommended torque value for tightening
fasteners.
• Pay special attention to single direction fixing accessories.
• Start and inspect oil circulation /lubrication system after assembly the engine.
