Vento Phantom R4i - Cam Shaft Holder Assembly

VENTO MOTORCYCLES
Rev no.01/ page 29of 84
1. Cylinder head cover fixing bolt 10~12N·M
2. Chain Tensioner bolt and fixing bolt 10~12 N·M
3. Cam shaft holder nut 22~25 N·M
4. Inlet pipe locknut 10~12 N·M
5. Timing bolt 10~12 N·M
CAM SHAFT HOLDER ASSEMBLY
D I S A S S E M B LY
A S S E M B LY
CAM SHAFT HOLDER & CAM SHAFT ASSY. ATMOLYSIS SHAFT RIGHT BEARING12
CAM SHAFT HOLDER ADJUSTING GASKET16
ROCKER SHAFT2 AUTO REDUCTOR OUT CIRCLE14 AND ROLLING
POLE,SPRING15
GASKET3AND ROCKER4 ATMOLYSIS SHAFT AND LEFT BEARING13
STOPPER BOARD5 ATMOLYSIS SHAFT SPROCKET ASSY.11
AXIS6AND BUSH7 ATMOLYSIS SHAFT ASSY.
MASS8AND SPRING9 ATMOLYSIS SHAFT SUPPORTER10
CAM SHAF HOLDER 10 AXES6BUSH7MASS8AND SPING9
CAM SHAFT ASSY. STOPPER BOARD5
CAM SHAFT SPROCKET11 ROCKER4AND GASKET3
CAM SHAFT RIGHT BEARING12CAM SHAFT LEFT BEARING R OCKER SHAFT(2)
AUTO REDUCTOR OUTSIDE CIRCLE14 BEARING,13 ATMOLYSIS SHAFT FIXER ASSY.
GASKET16AND CAM SHAFT17 ATMOLYSIS SHAFT FIXER AND ATMOLYSIS SHAFT
NOTE : When installing rocker shaft, remember to assemble
rocker with lubrication, and
keep groove of center rocker shaft on the same level as the hole of rocker seat.
