MOVABLE DRIVE FACE
NOTE:
• Before installing part (8), insert 3 cushion gaskets into (8).
• Bush2should be slide freely.
REMOVAL
Face fixed drive1
Bush2
Plate Drive8
Cushion gasket9
Roller 7
Washer3
Bush4
Washer6
Face movable drive5
INSTALLATION
Face movable drive5
Washer 6
Steel bush (4)
Washer 3
Roller 7
Cushion gasket9
Plate Drive 8
Bush2
Face fixed drive 1
