CHAPTER 5
CHASSIS
INSTALL
ATION OF
VEHICLE BODY
Specified Torque Value
NO. ITEM QTY. TORQUE
FRONT WHEEL/FRONT ABSORBER
1 Front wheel axis locknut 1 55-62Nm
2
Fixing bolt between front absorber and support under
connecting board assy.
4 37-44N.m
3 Fixing bolt for disc brake and front absorber 2 22-29N.m
Handlebar
1
Fixing bolt for handlebar and supporting under connecting
board
1 37-44N.m
Frame
1 Fixing bolt for frame and engine bracket 2 37-44N.m
2 Fixing bolt for frame and rear absorber 2 37-44N.m
Rear wheel/rear absorber
1 Rear wheel locknut 1 100-130Nm
2 Fixing bolt for left, rear absorber and engine 1 22-29N.m
3
Fixing bolt for right, rear absorber and muffler connecting
board
1 22-29N.m
Engine
1 Fixing bolt for engine and muffler 2 22-29N.m
2 Fixing bolt for engine and engine bracket 1 37-44N.m
