Vento Phantom R4i - Main Electrical Components Specification

VENTO MOTORCYCLES
Rev no.01/ page 77of 84
MAIN ELECTRICAL COMPONENTS SPECIFICATION
SOME IMPORTANT SPECIFICATION-ELECTRICAL
BATTERY CHARG
ING
SYSTEM
ITEM SPECIFICATION
Capacity 12Volt-6Ah/YTX7A-BS/YUASA
Specific gravity at (27) Fully charged
Needs charging
1.220~1.240
Below 1.220
Charging current 0.6 Amp
Battery
Charging time 8-12 hours
Capacity 114W at 5000rpm
Battery
charger
Battery charging coil resistance
at (20/68°f)
Between
Black and Black-White wiring
Less than 2 Ohms
Lamp cable Yellow and Green-White Less than 2 Ohms
VOLTAGE REGULATOR OUTPUT:
Regulated voltage for lighting circuit <14.5Volt
Rectified DC voltage for battery charging > 11.5 Volt
Rectified DC voltage for battery charging 0.6 to 2.0 Amp at 5000 RPM
