NOTE 1
Incase charging output is less than 0.6 Amp or more than 2.0Amp then replace the Voltage Regulator with new one
and recheck.
NOTE 2
AMMETER: -----Series connection inline with positive battery wire to measure DC –Amp.
VOLTMETER: ---Parallel connection between positive & negative terminal of the battery to measure DC-Volts.
Electrical starting power flow chart
Circuit process
Storage battery
Fuse
Main switch Alarm System
Stop switch
Start switch
Start relay
Start motor
Connect ground magnet motor
