Vento Phantom R4i - Muffler Assembly

VENTO MOTORCYCLES
Rev no.01/ page 60of 84
MUFFLER ASSEMBLY
Disassembly
Nut M813Flat washerφ811Spring
washerφ812,
Bolt M8X1252,bolt M8X404
Special nut5
Exhaust pipe assy.1
Exhaust pipe bush6
Bolt M8X3510, bolt M8X559
Nut M16X1.57
Outside orientation bush8
Muffler connecting board3
Inner orientation bush14
Assembly
Inner orientation bush14
Muffler connecting board3
Outside orientation bush8
Nut M16X1.57
Bolt M8X3510,bolt M8X559
Exhaust pipe bush6
Exhaust pipe assy.1
Special nut5
Bolt M8X1252, bolt M8X404
Flat gasket φ811, spring gasketφ812, nut
M813
