VENTO MOTORCYCLES

Rev no.01/ page 65of 84

1.Oil cap 5.Clip ring 9.Tension spring

2.Oil gasket 6.Bowl 10.Outlet oil hole

3.Inlet oil hole 7.Stopper 11.Supplement hole

4. Stopper anti-dust cover 8. Bowl 12.Master cylinder

MASTER CYLINDER ASSY.

Fig.6
