Vertical Edge 5000 - Appendix A Default Settings; IP5000 Specifications

Edge 5000 Installation / Configuration Guide
Appendix B
IP5000 Specifications
The table below provides the basic specifications of the IP Phone.
Item IP5000
Network Interface RJ-45 IEEE 802.3 Ethernet/Fast Ethernet switch port
PC/Workstation Interface RJ-45 IEEE 802.3 Ethernet/Fast Ethernet switch port
Power 802.3af or AC/DC Power Adapter
LED Indicators Message Indicator, Speakerphone, Mute, DND, Headset, Red LED
24 Programmable Buttons w/Red/Green LED
LCD 240 x 56 dot graphic
Physical Size (H x W x D) 206
x
235
x
51.2 cm
8.1 x 9.25 x 2 inches
Weight 771g
AC/DC Adaptor Output: 48VDC, 0.3A (max.)
Input: 100-240 VAC, 50/60 Hz.
Operation Temperature 0 - 40
o
C
Storage Temperature -20 - 60
o
C
Operation Humidity 10 - 85 % RH, non-condensing
Audio Acoustic Echo Canceller & Voice Active Detection
Codecs G.711, G.723.1/a, G.729a/b, and G.722
Release 1.0
September 2010
