CDP 3-13
Chapter 3: Using the LCD Configuration Menu
Edge 5000 Installation / Configuration Guide
• Press the digit, or move the cursor to 8.VLAN Settings using the [Next]-[Previous]
softkeys and press the [OK] softkey.
• Press the button, or move the cursor to 4.VLAN ID (PC) using the
[Next]-[Previous] softkeys and press the [OK] softkey.
• Input the VLAN ID (PC) port using the dial pad and press the [OK] softkey to save your
entry.
• Move to another parameter with the navigation buttons and continue the session, or
press the Settings ( ) button to exit the configuration session.
NOTE: Changing the VLAN ID (PC) port requires a reboot of the IP Phone; when you leave the menu,
you will receive a reboot notice. The IP Phone must reboot to utilize the new values entered.
To disable VLANs, assign the VLAN ID as zero (0).
CDP
IP Phones can be assigned to employ the Cisco® Discovery Protocol to determine if VLANs
are to be used and the associated VLAN Id. The CDP selection displays only if 'function_cdp'
is enabled in the configuration file, see Appendix D. As a default, the CDP selection displays.
To set the CDP status when 'function_cdp' is enabled:
• Press the Settings ( ) button. If the LCD Menu is locked, use the unlock
procedure. Refer to
page 3-4.
• Press the digit, or move the cursor to 1.Network Configuration using the
[Next]-[Previous] softkeys and press the [OK] softkey.
• Press the digit, or move the cursor to 9.CDP using the [Next]-[Previous] softkeys
and press the [OK] softkey.
• Select the desired softkey ([Yes] or [No]) to enable or disable CDP.
• Move to another parameter with the navigation buttons and continue the session or
press the Settings ( ) button to exit the configuration session.
NOTE: Changing the CDP status requires a reboot of the IP Phone; when you leave the menu, you will
receive a reboot notice. The IP Phone must reboot to utilize the new values entered.
When CDP is enabled, VLAN settings are overwritten.
