H-2
Appendix H: IP Phone Icons
Edge 5000 Installation / Configuration Guide
LOWER LINE ICONS
Forward icon indicates calls to the line are forwarded to another destination.
Message icon indicates there are messages waiting for the line
DND icon indicates the line is in DND and will not notify you of incoming calls on the line
Hold icon indicates there are calls on hold for the line
Busy icon indicates the line has an active call
Ring icon indicates the line has an incoming call
Available icon indicates the line is available for use
Unavailable icon indicates the line is not available for use
Phone Book icon indicates the Phone Book is being displayed
Conference icon indicates the line is presently in a conference call
