REV : 6
REV DATE : 4/19
DPN003193
Page :1 /1
Form No.: DPN001040_REV4
CABINET DIMENSIONAL DATA
LIEBERT CW
DOWNFLOW MODELS CW106 - CW114 W/ EC FANS
G
OVERALL
C
CABINET
A
OVERALL
76"
1930mm
MODELS WITH PRE-FILTERS
76"
1930mm
9"
229mm
B FILTER PLENUM
AIR RETURN
H
DUCT
FLANGE
B
DUCT
FLANGE
BOTTOM VIEW
FRAME ONLY
E
J
28"
711mm
28"
711mm
28"
711mm
31"
787mm
TYP.
33"
838mm
K
FRONT OF UNIT
CW106
1785 (810)
CW114 1925 (873)
122 (3099) 118 (2997) 35 (889) 31 (787) 120 (3048)
CHILLED
WATER
MODEL
DIMENSIONAL DATA inches (mm) NET
WEIGHT
lbs. (kg)A B C D E F G H J K
33 (838) 34-3/4 (883) 32 (813) 94 (2388) 2.88 (73)
SHADED AREA INDICATES
A RECOMMENDED CLEARANCE
OF 36" (914mm) BE PROVIDED
FOR COMPONENT ACCESS
AND FILTER REMOVAL
STANDARD PIPING
OPENING
ELECTRICAL
OPENINGS
NOTE:
1. FILTERS ARE ACCESSIBLE
THRU FRONT OF UNIT.
ACCESS PANEL LOCATED
ABOVE ELECTRICAL PANEL.
2. ELECTRICAL CONNECTIONS
CAN BE MADE FROM TOP
OR BOTTOM OF UNIT.
SHADED AREA INDICATES
A RECOMMENDED CLEARANCE
OF 36" (914mm) BE PROVIDED
FOR COMPONENT ACCESS
AND FILTER REMOVAL
NOTE:
MINIMUM CLEARANCE OF 24" (610mm) REQUIRED BELOW
THE UNIT TO LOWER FANS. FANS MAY ALSO REMAIN IN
UNIT IF DESIRED.
