Vertiv Liebert CW Series User Manual

REV : 5
REV DATE : 6/17
DPN003192
Page :1 /1
DOWNFLOW MODELS CW038 - CW084 W/ EC FANS
Form No.: DPN001040_REV4
CABINET DIMENSIONAL DATA
LIEBERT CW
CW038 840 (381)
CW041 900 (408)
CW051 1220 (553)
CW060 1250 (567)
CW076 1440 (653)
CW084 1540 (690)
50 (1270) 46 (1168)
35 (889) 32 (813)
48 (1219)
35 5/8 (905)
NET WT.
lb. (kg)F GE H J
DIMENSIONAL DATA inches (mm)
CHILLED
WATER
MODEL
A B C D
74 (1880)
99 (2515) 8 7/8 (225)
72 (1829)
97 (2464)
31 (787)
28 (711)
2 7/8 (73)
51 1/4 (1302)
60 3/4 (1543)
70 (1778)
95 (2413)
UNIT DIMENSIONAL DATA
C
CABINET
D
AIR
RETURN
A
OVERALL
B AIR
RETURN
MODELS
W/ PRE-FILTERS
F PLENUM
OVERALL
G
AIR RETURN
A
UNIT & PLENUM OVERALL
B
AIR RETURN
STANDARD PIPING, ELECTRICAL & AIR DISCHARGE OPENINGS
72"
1829mm
72"
1829mm
9"
229mm
F
OVERALL
FRONT OF UNIT
FRONT OF UNIT
FRONT OF UNIT
SHADED AREA INDICATES A RECOMMENDED
CLEARANCE OF 36" (914mm) BE PROVIDED
FOR COMPONENT ACCESS AND FILTER REMOVAL
ON ALL CW026-CW084 UNIT TYPES
SHADED AREA INDICATES
A RECOMMENDED CLEARANCE
OF 36" (914mm) BE PROVIDED
FOR COMPONENT ACCESS AND
FILTER REMOVAL ON ALL
CW026-CW084 UNIT TYPES
NOTES:
1. MINIMUM CLEARANCE OF 24" (610mm) REQUIRED BELOW
THE UNIT TO LOWER THE FANS. FANS MAY ALSO REMAIN
IN UNIT IF DESIRED.
2. VIEWS OF ELECTRICAL & AIR DISCHARGE OPENINGS ARE
FROM INSTALLER'S POINT OF VIEW.
CW038 - 041
Electrical
Openings
Standard Piping
Opening
E
H
31"
787mm
33"
838mm
J
CW051 - 060
E
H
24 1/4"
615mm
24 1/2"
624mm
33"
838mm
31"
787mm
TYP.
Standard Piping
Opening
Electrical
Openings
CW076 - 084
E
H
28 1/16"
713mm
28 1/16"
713mm
J
33"
838mm
31"
787mm
TYP.
Standard
Piping
Opening
J
Electrical
Openings
