11. Confirm that the UPS is operating in bypass mode. If not, then manually transfer the connected equipment to
bypass as follows:
a. Press and hold the Power button for 2 seconds.
b. Select Turn to bypass and press Enter.
12. Turn on the output breakers.
13. Power on the UPS by pressing and holding the Power button on the operation and display panel until the
confirmation dialog appears. Use the Up/Down arrows to select YES, then press Enter.
14. Turn OFF the maintenance bypass breaker and replace the upper connector cover screw.
15. Use the Power button to switch the output to the UPS inverter.
NOTE: The captive screws and maintenance bypass breaker cover is similar for all models. Figure 6.2 below, shows an
example on the 5 kVA model.
Figure 6.2 Maintenance Bypass Breaker Cover and Captive Screws
Item Description
1 Captive screws for POD
2 Connector cover screws
3 Maintenance bypass breaker
4 Programmable outlet maintenance bypass breaker
6.6 Firmware Updates
Firmware updates are available via the Vertiv website. Firmware update instructions are provided with the firmware download.
6 Maintenance Proprietary and Confidential ©2024 Vertiv Group Corp. 61
Vertiv™ Liebert® GXT5 UPS Installer/User Guide

Vertiv LIEBERT GXT5 Series Specifications

General

Model	LIEBERT GXT5 Series
Product Type	UPS
Topology	Double Conversion Online
Display	LCD
Form Factor	Tower, Rackmount
Output Voltage	200/208/220/230/240 VAC
Output Frequency	50/60Hz ±0.1Hz (battery mode)
Typical Backup Time	Varies by model and load
Communication Ports	USB, RS-232
Operating Temperature	0°C to 40°C (32°F to 104°F)
Relative Humidity	0% to 95% (non-condensing)
Dimensions	Varies by model
Weight	Varies by model
Certifications	UL, cUL, CE, RoHS
Battery Type	Valve Regulated Lead Acid (VRLA)
