8 Specifications
Model GXT5 5000HVRT5UXLN 8000HVRT5UXLN 10KHVRT5UXLN
Rating 5000 VA/5000 W 8000 VA/8000 W 10000 VA/10000 W
Dimensions, D×W×H, in. (mm)
Unit 16.9 x 24.8 x 8.5 (430 x 630 x 217)
Shipping 35.0 x 25.2 x 31.5 (890 x 640 x 800)
Weight, lb. (kg)
Unit 156.7 (71.1) 160.7 (72.9)
Shipping 202.8 (92) 239.3 (108.55)
Input AC
Operating Frequency, Nom. 50 or 60 Hz (factory default is 60 Hz)
Factory default VAC 208 VAC
User-configurable VAC
200/208/220/230/240 VAC
(Adjustable using operation/display configuration options)
Operating voltage range without
battery operation
176 – 288 VAC (100 – 176VAC with power derating)
Maximum Allowable VAC 288 VAC
Input Frequency without Battery
Operation
40 – 70 Hz
Input Power Connection PD5-CE6HDWRMBSU PD5-CE10HDWRMBSU
Output AC
AC-AC Efficiency 94% 95%
Factory default VAC Frequency 208 VAC, 60 Hz
Output Power Connection PD5-CE6HDWRMBSU PD5-CE10HDWRMBSU
Waveform Sine wave
Normal Mode Overload
> 150% minimum 200 mS
125 – 150% for 60 seconds
105 – 125% for 5 minutes
≤ 105% continuous
Internal Battery Charger
Charger Current, A 1.8 A default, maximum 5 A 1.8 A default, maximum 8 A
Battery Parameters
Type Valve-regulated, non-spillable, flame-retardant, lead acid
Table 8.1 UPS Specifications, 5 kVA to 10 kVA Models
8 Specifications Proprietary and Confidential ©2024 Vertiv Group Corp. 65
Vertiv™ Liebert® GXT5 UPS Installer/User Guide

Vertiv LIEBERT GXT5 Series Specifications

General

Model	LIEBERT GXT5 Series
Product Type	UPS
Topology	Double Conversion Online
Display	LCD
Form Factor	Tower, Rackmount
Output Voltage	200/208/220/230/240 VAC
Output Frequency	50/60Hz ±0.1Hz (battery mode)
Typical Backup Time	Varies by model and load
Communication Ports	USB, RS-232
Operating Temperature	0°C to 40°C (32°F to 104°F)
Relative Humidity	0% to 95% (non-condensing)
Dimensions	Varies by model
Weight	Varies by model
Certifications	UL, cUL, CE, RoHS
Battery Type	Valve Regulated Lead Acid (VRLA)
