Model GXT5 5000HVRT5UXLN 8000HVRT5UXLN 10KHVRT5UXLN
Rating 5000 VA/5000 W 8000 VA/8000 W 10000 VA/10000 W
Quantity x Voltage x Rating 16 x 12V x 9.0AH
Back-up time See Battery Run Times on page70.
Upper-limit selections +10%, +15%, +20%; default +10%.
Lower-limit selections -10%, -15%, -20%; default -15%
Disable-bypass operation When the input frequency prevents synchronous operation
Environmental
Operating Temperature, °F (°C) 32 to 104 (0 to 40) (no derating)
Extended Operating Temperature, °F
(°C)
32 to 122 (0 to 50); output derated by 1% per 1 °C above 40 °C
Storage Temperature, °F (°C) 5 to 104 (–15 to 40)
Relative Humidity 0 – 95% non-condensing
Operating Elevation Up to 3,000 m (9,842.5 ft) at 25°C (77°F) without derating
Audible Noise <55 dBA, at 1 meter from the front, <50 dBA, at 1 meter from rear or sides
Agency
Safety
IEC 62040-1: 2017+A1:2021
AS 62040.1:2019
EN IEC 62040-1:2019+A11:2021
BS EN IEC 62040-1:2019+A11:2021,
GS mark;
UL1778, c-UL listed
EMI/EMC/C-Tick EMC
IEC/EN/AS 62040-2 2nd
Ed (Cat 2 – Table 6); FCC Part 15 (Class A)
CISPR22 Class A (RFI)
ESD
IEC/EN EN61000-4-2,
Level 4, Criteria A
Radiated Susceptibility
IEC/EN EN61000-4-3,
Level 3, Criteria A
Electrical Fast Transient
IEC/EN EN61000-4-4,
Level 4, Criteria A
Table 8.1 UPS Specifications, 5 kVA to 10 kVA Models (continued)
66 Proprietary and Confidential ©2024 Vertiv Group Corp. 8 Specifications
Vertiv™ Liebert® GXT5 UPS Installer/User Guide
