Model GXT5 5000HVRT5UXLN 8000HVRT5UXLN 10KHVRT5UXLN
Rating 5000 VA/5000 W 8000 VA/8000 W 10000 VA/10000 W
Surge Immunity
IEC/EN EN61000-4-5,
Level 4, Criteria A;
ANSI C62.41 Category B
Transportation ISTA Procedure 1E
*For GXT5-10KHVRT5UXLN —The product fulfills the requirement of IEC 62040-1: 2017+A1:2021, AS 62040.1:2019, EN IEC 62040-1:2019+A11:2021 and BS
EN IEC 62040-1:2019+A11:2021.
Table 8.1 UPS Specifications, 5 kVA to 10 kVA Models (continued)
Model GXT5 3KL620RT2UXL 3KL630RT2UXL 6KL630RT2UXL
Rating 3000 VA/2700 W 3000 VA/3000 W 4900 VA/4900 W
Dimensions, D×W×H, in. (mm)
Unit 21.3 x 16.9 x 3.4(540 × 430 × 85) 16.9 x 23.6 x 8.5 (430 x 600 x 217)
Shipping 28.2 x 22.4 x 10.3(717 x 570 x 262) 25.4 x 32.1 x 20.5 (646 x 816 x 520)
Weight, lb.(kg)
Unit 65.1 (29.6) 67.1 (30.5) 149.1 (68)
Shipping 79.2 (36) 80.5 (36.6) 202.8 (92)
Input AC
Operating Frequency, Nom. 50 or 60 Hz (factory default is 60 Hz)
Factory default VAC 208 VAC
User-configurable VAC 200/208/220/230/240 VAC (Adjustable using operation/display configuration options)
90% ~ 100% loading 182~ 191VAC/288VAC
175 – 280 VAC
70% ~ 90% loading 164 ~182VAC/288VAC
28% ~ 70% loading 129~ 164VAC/288VAC
0% ~ 28% loading 129VAC/288VAC
Frequency 40 Hz ~ 70 Hz; auto-sensing
Input Power Cord L6-20P L6-30P L6-30P Plug (on PD5-L630 POD)
Output AC
Output Receptacles 2x L6-20R and 2x L6-15R 2x L6-30R and 2x L6-15R
(2) L6-20R and (2) L6-30R on 12-in.
(300-mm) cords (on PD5-L630
POD)
Voltage 208VAC ±3%
Waveform Sine wave
Normal Mode Overload
>200% for 250ms
150- 200% for 2 seconds
105% to 125% for 5 minutes
125% to 150% for 60 seconds
Table 8.2 UPS Specifications, 3KL620, 3KL630, and 6KL630 models
8 Specifications Proprietary and Confidential ©2024 Vertiv Group Corp. 67
Vertiv™ Liebert® GXT5 UPS Installer/User Guide
