Model GXT5 3KL620RT2UXL 3KL630RT2UXL 6KL630RT2UXL
Rating 3000 VA/2700 W 3000 VA/3000 W 4900 VA/4900 W
125-150% for 10 seconds
105-125% 15 seconds
≤ 105% continuous
>150% (impact load) minimum 20
ms
≤ 105% continuous
Internal Charger
Charging Current 1.8 A (default), maximum 8 A 1.8 A (default), maximum 5 A
Battery Parameters
Type Valve-regulated, non-spillable, lead acid
Quantity x Voltage x Rating 6 × 12 V × 9.0 Ah 16 x 12 V x 9.0 Ah
Back-up time See Battery Run Times on page70.
Recharge time 3 Hours to 90% capacity after full discharge into 100% load
5 hours to 90% capacity after full
discharge into 100% load
Environmental
Operating Temperature, °F (°C) 32 to 104 (0 to 40) (no derating)
Extended Operating Temperature, °F
(°C)
32 to 122 (0 to 50); output derated by 1% per 1°C above 40°C
Storage Temperature, °F (°C) –4 to 140 (–20 to 60) [batteries are from 5 to 104 (–15 to 40)]
Relative Humidity 0% – 95% non-condensing
Operating Elevation Up to 10,000 ft (3,000 m) at 77°F (25°C) without derating
Audible Noise <48 dBA max. at 3 ft (1 m) front and sides, <48 dBA max. at 3 ft (1 m) rear
<50 dBA, at 3 ft (1 m) from the front
and sides, <55 dBA, at 3 ft (1 m) from
rear
Agency
Safety
EN 62040-1:2008+A1:2013 GS mark UL 1778 5th Edition and CSA 22.2 No.
107.1
UL1778, c-UL listed
EMC EN 62040-2:2006 EN 61000-3-2:2014 EN 61000-3-3:2013
EN61000-4-2 EN61000-4-3
EN61000-4-4
Transportation ISTA Procedure 1A ISTA Procedure 1E
Surge Immunity ANSI C62.41 Category B (6kV/3kA) IEC 61000-4-5
RFI/EMI CISPR22 Class A FCC Part 15 (Class A)
Table 8.2 UPS Specifications, 3KL620, 3KL630, and 6KL630 models (continued)
68 Proprietary and Confidential ©2024 Vertiv Group Corp. 8 Specifications
Vertiv™ Liebert® GXT5 UPS Installer/User Guide
