• Disable (default)
5.2.5 Control Screen
The Control screen offers UPS-control options.
To adjust the UPS controls:
1. At the main menu, select the Control icon, and press Enter.
2. Use the arrow buttons to move the cursor to the option, then press Enter.
Figure 5.6 Control Screen
Control Options
Turn on/off/to bypass
Opens the dialog to change operating modes, see Operating the UPS on page33.
Mute/Unmute audible alarm
Silences or un-silences the audible alarm, see Silencing the Audible Alarm on page33.
Start/Stop battery manual test
Starts the battery self test manually. If the manual self test is already running, stop the self test.
Clear faults
Clears displayed faults after the issue causing the fault is resolved, see Table 7.2 on page63, for a description of
the faults.
Reset power statistics
Resets the values tracked to calculate the Efficiency graph, see About Screen on page52.
5.2.6 Log Screen
The Log Screen offers tabs that list the current alarms and the alarm/event history. Table 5.4 on the next page, describes the
alarm messages you may see in the logs.
To view the logs:
1. At the main menu, select the Log icon, and press Enter.
5 Operation and Display Panel Proprietary and Confidential ©2024 Vertiv Group Corp. 49
Vertiv™ Liebert® GXT5 UPS Installer/User Guide

Vertiv LIEBERT GXT5 Series Specifications

General

Model	LIEBERT GXT5 Series
Product Type	UPS
Topology	Double Conversion Online
Display	LCD
Form Factor	Tower, Rackmount
Output Voltage	200/208/220/230/240 VAC
Output Frequency	50/60Hz ±0.1Hz (battery mode)
Typical Backup Time	Varies by model and load
Communication Ports	USB, RS-232
Operating Temperature	0°C to 40°C (32°F to 104°F)
Relative Humidity	0% to 95% (non-condensing)
Dimensions	Varies by model
Weight	Varies by model
Certifications	UL, cUL, CE, RoHS
Battery Type	Valve Regulated Lead Acid (VRLA)
