Vertiv Liebert GXT5 Installer/User Guide

4 Operating the UPS 33
4.1 Silencing the Audible Alarm 33
4.2 Starting-up the UPS 33
4.3 Transferring to Battery Mode 33
4.4 Transferring from Normal to Bypass Mode 34
4.5 Transferring from Bypass to Normal Mode 34
4.6 Shutting Down the UPS Completely 34
4.7 Remote Emergency Power Off (REPO) 34
5 Operation and Display Panel 35
5.1 LED Indicators 36
5.2 LCD Menu and Screens 36
5.2.1 Start-up and Flow Screens 36
5.2.2 Main Menu 37
5.2.3 Status Screen 38
5.2.4 Settings Submenu 41
5.2.5 Control Screen 47
5.2.6 Log Screen 48
5.2.7 About Screen 52
5.3 Editing Display and Operation Settings 54
5.3.1 Setting Prompts 54
5.3.2 Changing the Password 55
5.3.3 Selecting the Display Language 56
5.3.4 Setting the Date and Time 56
6 Maintenance 57
6.1 Replacing Batteries 57
6.2 Charging Batteries 59
6.3 Checking UPS Operation 59
6.4 Cleaning the UPS 59
6.5 Replacing the UPS using Maintenance Bypass 60
6.6 Firmware Updates 61
7 Troubleshooting 63
7.1 Symptoms that Require Troubleshooting 63
7.2 Audible Alarm (Buzzer) 63
7.2.1 Faults 63
7.3 Troubleshooting UPS Issues 64
8 Specification 65
8.1 Battery Run Times 69
Appendices 73
Appendix A: Technical Support and Contacts 73
Appendix B: Open Source Software Legal Notices 75
ii Proprietary and Confidential ©2024 Vertiv Group Corp.
Vertiv™ Liebert® GXT5 UPS Installer/User Guide

Vertiv Liebert GXT5 Specifications

General

Output Voltage	200/208/220/230/240 VAC
Topology	Double Conversion Online
Input Voltage	200/208/220/230/240 VAC
Output Frequency	50/60 Hz
Display	LCD
Operating Temperature	0 to 40°C (32 to 104°F)
Dimensions	Varies by model
Weight	Varies by model
Form Factor	Rack/Tower
Power Capacity	1-20 kVA
Communication Ports	USB, RS-232
Waveform Type	Sinewave
Input Frequency	50/60 Hz
Power Factor	0.9
Operating Humidity	0-95% non-condensing
Battery Type	Valve-regulated lead acid (VRLA)
