Model Number GXT5-EBC144VRT2U GXT5-EBC288VRT4U GXT5-EBC288VRT8U
Used W/UPS Model 5 – 6 KVA Models 8 – 10 KVA Models 15 – 20 KVA Models
Dimensions, D×W×H, in. (mm)
Unit (with bezel) 17.5 x 26.5 x 3.5 (430 x 650 x 85) 17.5 x 26.5 x 7.1 (430 x 650 x 173) 16.9 x 26.7 x 13.6 (430 x 680 x 346)
Shipping 35.5 x 25.7 x 19.8 (845 x 630 x 485) 35.5 x 25.7 x 23.2 (845 x 630 x 570) 26.4 x 34.6 x 34.1 (670 x 880 x 867)
Weight, lb.(Kg)
Unit 81.6 (37) 189.6 (86) 361.6 (164)
Shipping 123.5 233.7 418.9 (190)
Battery
Type Valve-regulated, non-spillable, lead acid
Qty × Voltage 12 x 12V 24 x 12V 48 x 12V
Backup time See Battery Run Times below.
Environmental Requirements
Operating Temperature, °F (°C) 32 to 104 (0 to 40)
Storage Temperature, °F (°C) 5 to 122 (–15 to 50)
Relative Humidity 0% to 95%, non-condensing
Operating Elevation Up to 10,000 ft (3,000 m) at 104 °F (40 °C)
Agency
Safety UL1778 4th Edition and CSA 22.2 No. 107.3
RFI/EMI FCC Part 15 Class A
Transportation ISTA Procedure 1A
Table 8.5 External Battery Cabinet Specifications
8.1 Battery Run Times
NOTE: Run times in this table are approximate. Times are based on new, fully charged, standard battery modules at a
temperature of 77 °F (25 °C) with 100% resistive UPS loading. Run times listed above can vary by ±5% due to
manufacturing variances of the individual batteries.
Load
Internal
Battery
Only
Number of External Battery Cabinets
1 2 3 4 5 6 7 8 9 10
% VA W Minutes
10 500 500 87.0 195.0 311.0 427.5 543.5 660.0 776.0 892.5 1009.0 1125.0 1241.5
20 1000 1000 41.5 94.0 149.0 211.0 273.5 335.5 397.5 460.0 522.0 584.5 646.5
30 1500 1500 24.5 61.0 97.0 133.0 175.0 218.0 260.5 303.0 345.5 388.0 430.5
Table 8.6 Battery Run Time in Minutes, GXT5-5000MVRT4UXLN
