Vertiv Liebert GXT5 - Page 72

Model PD5- 101 102 103 104 105 106 107 108 109
Dimensions, D×W×H, in. (mm)
Unit 7.4 x 5.7 (188 x 145)
Shipping 11.9 x 20.6 x 8.7 (302 x 522 x 220)
Weight, lb.(kg)
Unit 4.4 (2) 6.6 (3) 4.4 (2) 6.6 (3)
Shipping 6.6 (3) 8.8 (4) 6.6 (3) 8.8 (4)
Electrical Specifications
Amp Rating 2 pole 60 A input breaker
Input power
connection
Custom Connector
3W+G (L1-L2-N-G) to UPS
Output power
connection
(2)
L6-30R
(8)
5-20R
(4)
L6-20R
(4)
5-20R
(4)
5-20R
(4)
L6-30R
(4)
5-20R
(2)
L6-30R
(2)
L6-20R
(4)
5-20R
(2)
L5-30R
(2)
L5-20R
(4)
L6-20R
(4)
L5-20R
(4)
L5-20R
(4)
5-15/20R
(2)
L6-20R
(2)
L6-20R
(2)
L14-30R
Table 8.3 POD Specifications for 8 kVA to 20 kVA Models
Model PD2- 200 201 202 204
Dimensions, D×W×H, in. (mm)
Unit 7.4 x 5.7 (188 x 145)
Shipping 11.9 x 20.6 x 8.7 (302 x 522 x 220)
Weight, lb.(kg)
Unit 6.6 (3) 4.4 (2) 6.6 (3)
Shipping 15 (6.8) 6.6 (3) 15 (6.8)
Electrical Specifications
Amp Rating 2 pole 60 A input breaker
Input power connection
Custom Connector
3W+G (L1-L2-N-G) to UPS
Output power connection
(4) IEC320-C19
(4) IEC320-C13
(2) IEC320-C19
(8) IEC320-C13
(12) IEC320-C13
(2) IEC309-32A
(4) IEC320-C13
Table 8.4 Additional POD Specifications for 8 kVA to 20 kVA Models
68 Proprietary and Confidential ©2024 Vertiv Group Corp. 8 Specification
Vertiv™ Liebert® GXT5 UPS Installer/User Guide
