5.7.3 Liebert LDMF Alarms
If any alarms are present when parameter screens are accessed with the Main, Subfeeds or
Branch Breakers keys, the Alarm Screen appears, as shown in the example below.
• Press F4 (Back) to view details about the alarm on the Panelboard Main screen.
• The alarm activates the Audible Alarm and the red Alarm LED.
• Press the Silence/Reset key once to silence the audible alarm.
• Press the Silence/Reset key a second time to clear the alarm. If all alarms are reset, the display returns to
the Main Alarm screen.
• If the alarm condition persists, a new alarm is generated and the sequence is repeated.
s
NEW ALARM(S) PRESENT
PRESS THE SILENCE/RESET
KEY TO RESET THE ALARM(S)
PRESS BACK TO GO TO THE PANEL
BOARD MAIN TO REVIEW THE ALARM
TYPE(S) AND LOCATION(S)
BACK
F2 F3 F4 HELPF1
