Vertiv™ | Liebert® LDMF™ Distribution Monitoring User Manual | 46
5.7.4 Liebert LDMF Screens
Figure 2 Main panelboard screens—examples
NOTE
The images below are for representation of the menu items only. The actual display including the
Controls and Indicators shown in the images below may not be present.
Panelboard Main Screen
(if no alarms are present)
Panelboard Alarms
(appears only if alarms are present)
Panelboard
Voltages
Panelboard
Currents
Panelboard
Power Values
Panelboard
Crest Factor (CF)
s
PANEL BOARD LABEL
NO ALARMS PRESENT
NEXT SUB BRANCH
MAIN SEQ FEEDS BRKRS
F2 F3 F4 HELPF1
s
PANEL BOARD LABEL
LDM SUMM ALRM PANEL BOARD ALRM
OVER VOLT ALRM UNDER VOLT ALRM
PH OVER CURRENT NEUT OVER CURR
OVER CURR WARN GND OVER CURR ALRM
NEXT SUB BRANCH
MAIN SEQ FEEDS BRKRS
F2 F3 F4 HELPF1
s
PANEL BOARD LABEL
V X-Y = XXX V X-N = XXX
V Y-Z = XXX V Y-N = XXX
V Z-X = XXX V Z-N = XXX
NEXT SUB BRANCH
MAIN SEQ FEEDS BREAKERS
F2 F3 F4 HELPF1
s
PANEL BOARD LABEL
IX = XXXX IN = XXXX
IY = XXXX IG = XX.X
IZ = XXXX
NEXT SUB BRANCH
MAIN SEQ FEEDS BRKRS
F2 F3 F4 HELPF1
s
PANEL BOARD LABEL
kVA = XXXX PF = 0.XX
kW = XXXX %LD = XXX
kWH = XXXXXXXX
NEXT SUB BRANCH
MAIN SEQ FEEDS BRKRS
F2 F3 F4 HELPF1
s
PANEL BOARD LABEL
IX CF = X.X
IY CF = X.X
IZ CF = XX.X
NEXT SUB BRANCH
MAIN SEQ FEEDS BRKRS
F2 F3 F4 HELPF1
