17
Vertiv I Liebert LPC I User Manual
1.4.9 Liquid Indicator
The liquid indicator works as a toolset used for observing the refrigerant state, specifically
the moisture content of the system. When the moisture content exceeds the standard or a
particular limit, the color will be changed indicating the irregularities in the moisture content.
1.4.10 Condenser
The Liebert range of Air Cooled Condensers offer unique benefits including sharp design,
antirust aluminum cabinets, low sound levels, and reliable operation over a wide range of
ambient conditions.
Figure 1-9 shows a pictorial depiction of the Condenser:
Figure 1-9 Condenser
Condenser sizing parameter
Sizing of the condenser is based on the ambient temperature as mentioned in the
Table 2.1.
Table 2.1
≤ 40
LSF24-R3
> 40
LSF32-R3
For more information on the condenser, refer to the separate condenser manual
which explains the entire condenser ecosystem in detail.
