Vertiv Liebert LPC Series User Manual

30
Vertiv I Liebert LPC I User Manual
2.6 Product Dimensions
The dimensions of the indoor unit are displayed in Figure 2-14:
Figure 2-14 Dimensions of the Indoor unit
Specifications are shown in the table displayed in table 2.1
 Dimensions and Weight of the Indoor unit
Table 2.1
Models Model Dimensions(mm) Net Weight (Kg)
L1015 730x845x1975 (WxDxH) 280
2.6.1 Plenum Dimensions
The Plenum is an assembly of all the components in the unit. The following table 2.2 displays
the dimensions of a plenum:
Table 2.2
Type Depth (mm) Width (mm) Height (mm)
L1015 850 (D) 730 (W) 400 (600 optional) (H)
