Vertiv I Liebert LPC I User Manual
Similar to the Unpacking explained in the section 2.1.2 in the manual, the obliquity needs to
be maintained with an angle inclination of 75% TO 105%.
Figure 2-6 Moving obliquity
•
Upon arrival of the unit, prior to unpacking, verify that the labeled matches
the bill of lading. Inspect and check all items for damage, either visible or
concealed.
•
Damage should be immediately reported to the carrier. A damage claim
needs to be filled and a copy of the same must be sent to Vertiv Co. or the
authorized sales representative.
2.1.4 Removal of external package
The chilled water version uses the international packaging.
Following are the procedures that need to be adhered to strictly for removing the external
package:
1) Use a hammer or straight screwdriver to straighten the hook as displayed in Figure 2-
7 to view the procedure:
Figure 2-7 Straightening the hook
